How to Read a Rim Size

There are three common wheel sizes that are stamped or cast into the back side of the hub. These sizes are important to know if you want to put the wheel on your car. However, there are two other measurements that can be just as important in fitting the wheel and the car together properly.

The size of the rim is written on the back of the hub. It is measured in three ways: diameter, width and bolt pattern. For example, a rim with the size 14 by 6 by 4.5 means that the diameter of the rim is 14 inches and it will fit most 14-inch tires. The 6 in the middle means that the width of the rim is 6 inches.

You want to make sure that the rim size is compatible with the size of your tire. This is important because if the rim size is too big or too small, it can be dangerous for your car. The bolt pattern is the distance between two of the bolt holes on the rim. This number also tells you if the rim will fit on your car or not.

To measure the rim size, use a measuring tape to measure the width and diameter of the rim. The diameter is measured from one side of the rim to the other, and the width is measured from the bottom of one bead to the bottom of another bead. To find out the bolt pattern, measure between the bolt holes in order to see how far they are apart.

The rim size is important to know if the rim will work with the tire and vehicle application. The backspace and offset of the rim are also important measurements to determine this.

Take a rim size by putting a straight edge across the rim of the rim and dropping it down to the face of the wheel. Next, write down how long it is on your paper.

You can figure out a rim size data by wheelssize.com. The hub is the middle of the rim. If it's not in the middle of the rim, then you need to know if it's a positive or negative offset. Some states don't allow tires to go over the edge of the wheel well, so a positive offset rim can push the tire back far enough that it doesn't violate those laws.

The size of a wheel can help us choose the right wheel for our customer. Sometimes there are similar-looking wheels with different sizes. By knowing the size of the wheel, we can be sure to get the right one for our customer. Some companies even offer the same style of wheel in multiple sizes, so it is important to know not just what the wheel looks like but also its size.
